AV Monografías 261-262 Spain Yearbook 2024 - Robert Olnick Pavilion

By Luis Fernández Galiano

Mar. 14, 2024

Inaugurado en 2017 en la villa de Cold Spring, a las afueras de Nueva York, el MagaZZino Italian Art está concebido como un espacio en el que los visitantes pueden participar, observar y contemplar la relación entre el arte italiano de posguerra y con-temporáneo. Proyectado y construido por Miguel Quismondo, el museo parte de la rehabilitación de un antiguo almacén de productos lácteos, y consiste en un volumen de 1.800 m' diseñado para albergar la colección privada de arte italiano de sus funda-dores, Nancy Olnick y Giorgio Spanu.

El éxito del MagaZZino ha sido tal que la familia Olnick Spanu ha decidido ampliar sus instalaciones construyendo un nuevo edificio, el Pabellón Robert Olnick, un volumen de hormigón con forma de paralelepipedo que alberga en sus dos plantas la colección de cristal de Murano, la cafeteria y otras áreas destinadas a muestras de carácter temporal.

El proyecto pone especial énfasis en. el área expositiva principal: un espacio blanco, cúbico e isótropo que funciona como punto focal del museo. Un espacio isótropo tiene las mismas propieda-des en todas direcciones. Asi, si se pudiera volar desde el centro, el espacio seria idéntico desde cualquier punto. En ese espacio, de dimensiones 10x 10x 10m, se practica en cada esquina una aber-tura de 2, 10x 2,10 x2,10x2, 10m, para que por alli pueda entrar el sol en cualquier momento del dia. Se consigue de esta manera un efecto espacial de gran potencia y singularidad. El tamaño del hueco de 2,10 permite que, al ubicarse en paredes que están en contacto con el suelo, las dimensiones sean adecuadas para servir de paso. Los dos huecos asi colocados serán puertas de entrada al blanco y lumi-noso recinto cúbico. Siguiendo una lógica sencilla, se elimina la abertura correspondiente al plano del suelo. Además, al perforar un agujero de 2,1 0x 2,10 de profundidad en el centro de la pared, es posible entender toda la operación espacial de un vistazo.

Este nuevo edificio debe completar y com-plementar el edificio principal del MagaZZino. Para ello se dispone en barra perpendicular a este, creando entre ambos un recinto unitario. La am-pliación se retira del conjunto la distancia adecua-da para resolver temas luncionales. La crujia de 1Im es semejante a la de los edificios existentes, al igual que la altura de cornisa, lo que garantiza la buena relación entre ellos.

La unión entre ambos edificios se resuelve con una avenida, un plano común de acceso que, al atra-vesar el edificio nuevo, permite una transparencia en planta baja como fondo de perspectiva; ese espa-cio transparente es el vestibulo del nuevo edificio.

Photo credits: Javier Callejas, Marco Anelli

https://arquitecturaviva.com/publicaciones/av-monografias/espana-2024

A person standing inside a modern, minimalistic white architectural space with large open areas, high ceilings, and natural light entering from windows. The space features clean lines and geometric shapes.
Architectural blueprint of a multi-story building with sections showing interior layouts, including galleries, offices, storage rooms, and a lobby. The top left corner features a series of lit screens displaying geometric light patterns.
A white gourmet burger with lettuce, tomato, cheese, and bacon on a toasted bun, served with crinkle-cut fries.

AV Proyectos 120 – Alberto Campo Baeza - Pabellón Robert Olnick

By Luis Fernández Galiano

Sep. 26, 2023

El pabellón se posa como una barra perpendicular al edificio principal. Sus proporciones son similares a las de las construcciones existentes, unificando el espacio circundante, y los interiores se diseñan pensando en la futura disposición de la colección.

Photo credits: Javier Callejas, Marco Anelli

https://arquitecturaviva.com/publicaciones/av-proyectos/alberto-campo-baeza-3900

Cover of architectural magazine 'ARq Vis Viv' featuring the interior of a modern, minimalist white building with angular walls and a single person standing near an opening in the wall.
Photograph of the Alberto Campo Baeza + Miguel Quisondon Robert Olnick Pavilion in Cold Spring, New York, showing a modern, minimalist concrete building with sharp angles and small windows, surrounded by greenery and a partly cloudy sky.
Architectural design board featuring a rendered aerial view of a modern building complex, floor plans, hand-drawn sketches, a perspective drawing, and an exterior photograph of the finished concrete building set against greenery.
A close-up of a black and white rabbit resting on a green plant.

Arquitectura Viva N.259 – Tras el terror

By Luis Fernández Galiano

Oct. 7, 2023

Cajas Blancas New York

https://arquitecturaviva.com/publications/av/tras-el-terror

Aerial view of a city block showing damaged and destroyed buildings with rubble, debris, and a large circular hole in the ground, indicating destruction.
Close-up of a green church bell with a white stone cross on top, set against a cloudy sky.

Robert Olnick Pavilion in Cold Spring, New York

By Luis Fernández Galiano

Sep. 29, 2023

The Robert Olnick Pavilion, designed by the architects Alberto Campo Baeza and Miguel Quismondo, is an extension of the museum Magazzino Italiam Art, in Cold Spring (New York). Arranged perpendicularly to the existing building, separated from it, the simple and sedate rectangular volume, a concrete parallelepiped, harbors the institution’s Murano glass collection, more exhibition galleries, and a café. On top is a 10m3 cube. The white space presents the same characteristics in all directions. At every corner, a 2.1 x 2.1-meter opening lets daylight in.

Photo credits: Javier Callejas, Marco Anelli, William Mulvihill

https://arquitecturaviva.com/works/pabellon-robert-olnick-en-cold-springs

Minimalist white interior with geometric cutouts and natural light, showing windows and a view of trees outside.
Modern concrete building on a grassy hillside, surrounded by lush green trees and hills in the background under a partly cloudy sky.
Modern building with concrete walls and an illuminated garage entrance at dusk, surrounded by trees.
Close-up of a child's hand holding a syringe near a child's arm.

Robert Olnick Pavilion, Cold Spring (in project)

By Luis Fernández Galiano

Aug 1, 2021

Sitting perpendicular to the main building of Magazzino Italian Art, which it completes and extends, the simple and sober volume of the new pavilion creates a unitary plane between both...

Photo credits: Alberto Campo Baeza, J.C Bragado & J.Mingorance (MQ Architecture)

https://arquitecturaviva.com/works/pabellon-robert-olnick-en-cold-springs

Aerial view of a modern building complex surrounded by trees and greenery, with roads and pathways leading to the buildings.
Close-up of a dark brown animal with a short tail, likely a dog, sitting on a concrete sidewalk with trees and grass in the background.

AV Monografías 236 – Alberto Campo Baeza

By Luis Fernández Galiano

2021

En un impresionante lugar junto al río Hudson se decide establecer un plano, una plataforma que, subrayando el paisaje, intentara realzarlo.

Para ello se construye una gran caja de 122x54 pies y 12 de alto. Con recias paredes de hormigón que acentúan su relación con la tierra. La cubierta es plana y de travertino, para establecernos sobre ella.

Y para protegernos del sol y la lluvia, levantamos sobre el plano de piedra una cubierta ligera de 100x40 pies a 9 pies de alto, sostenida por 10 pilares cilíndricos de acero ordenados en una cuadrícula de 20x20 pies. Esta cubierta vuela 10 pies en todos sus bordes. Y para acondicionar ese espacio, lo acristalamos con una caja de vidrio de 94x25 pies. La caja acoge en su interior los pilares de atrás y deja fuera los de delante, para acentuar más la transparencia...

Photo credits: Javier Callejas, Miguel Quismondo, Hisao Suzuki

https://arquitecturaviva.com/publicaciones/av-monografias/alberto-campo-baeza

Cover of a magazine featuring a serene beach scene with a person walking on a concrete platform towards the ocean, under a partly cloudy sky.
Modern living room with large glass windows overlooking green trees, white sofa, colorful wall art, black chair, wicker chairs, and minimal decor.
Modern white house with large glass windows and a flat roof, surrounded by trees with fall foliage and a lush green lawn.
A close-up view of a bird perched on a branch among green leaves.

Arquitectura Viva N.205 – America Imports

By Luis Fernández Galiano

Jun. 30, 2018

Refurbishing what was originally a dairy distribution center, built back in the 1960s, Mazazzino Italian Art is thought out to be home to a private collection of postwar Italian art. Located in Cold Spring, a town in upstate NewYork, the private museum renovates and enlarges an L-shaped building, making a complete rectangle out of it, on plan, and forming a central courtyard to resolve lighting issues and facilitate circulation.

The design makes an autonomous structure stretch parallel to the longer side of the existing volume, and connects the two parts of the museum with two glass passages that emphasize the lightness of the new construction. The old storehouse thus opens onto the courtyard, while the enlargement gives a panoramic view of the Cold Spring wetlands. The central courtyard, for its part, functions as an extension of the foyer; and the circulation flow is configured, by means of it, as a simple ring that lends itself to the creation of an intuitive route through the entire exhibition.

The construction techniques and materials used in the project are simple: the wall of concrete, poured into formworks on the site to form phenolic panels, gives rise to the skin of the new container; the pitched roof is executed with metal trusses; and the interior walls are painted white so that full attention is not on them, but on the art works on display.

Photo credits: Javier Callejas, Montse Zamorano

https://arquitecturaviva.com/publications/av/america-imports

Cover of Arquitetura Viva magazine featuring an interior view of a modern building with visible structural beams and glass facade, and people walking inside.
People viewing artwork in a modern art gallery with white walls and a glass ceiling.
Architectural blueprint of a building cross-section showing structural details.
A computer screen displaying a Microsoft Excel spreadsheet with rows and columns of data.

Italian Art Museum, NY – Miguel Quismondo

By Luis Fernández Galiano

Jun. 30, 2018

Refurbishing what was originally a dairy distribution center, built back in the 1960s, Mazazzino Italian Art is thought out to be home to a private collection of postwar Italian art. Located in Cold Spring, a town in upstate NewYork, the private museum renovates and enlarges an L-shaped building, making a complete rectangle out of it, on plan, and forming a central courtyard to resolve lighting issues and facilitate circulation.

The design makes an autonomous structure stretch parallel to the longer side of the existing volume, and connects the two parts of the museum with two glass passages that emphasize the lightness of the new construction. The old storehouse thus opens onto the courtyard, while the enlargement gives a panoramic view of the Cold Spring wetlands. The central courtyard, for its part, functions as an extension of the foyer; and the circulation flow is configured, by means of it, as a simple ring that lends itself to the creation of an intuitive route through the entire exhibition.

The construction techniques and materials used in the project are simple: the wall of concrete, poured into formworks on the site to form phenolic panels, gives rise to the skin of the new container; the pitched roof is executed with metal trusses; and the interior walls are painted white so that full attention is not on them, but on the art works on display.

Photo credits: Javier Callejas, Montse Zamorano

https://arquitecturaviva.com/works/italian-art-museum-ny

Modern white building with a rectangular opening in the center, set against a cloudy sky with greenery in the foreground.
Interior view of a modern building with large glass walls and concrete flooring, overlooking a pond and green landscape.
Modern building with white and concrete walls, surrounded by greenery and a mountainous background, with a person walking near the trees.
A close-up of four different colored nail polishes in glass bottles

Olnick Spanu House, Garrison

By Luis Fernández Galiano

2021

For an impressive spot along the Hudson River we established a plane, a platform facing the landscape spread out before us which would have the effect of enhancing it.

A large box – 122 feet long, 54 wide, 12 high – was built with sturdy concrete walls, accentuating its rapport with the land. The roof is flat and given a stone pavement so that it can be used.

And for protection against sun and rain, over the stone plane rose a light roof 100 feet long, 40 wide, and 9 tall, held up by 10 cylindrical steel pillars arranged on a 20x20-foot grid. It cantilevers 10 feet all around. So that the space could be inhabited, we put a glass box – 94 feet long, 25 wide – under the roof. It incorporates the back row of columns, but leaves the front ones outside to accentuate its transparency...

Photo credits: Javier Callejas, Miguel Quismondo, Hisao Suzuki

https://arquitecturaviva.com/works/casa-olnick-spanu-garrison

Modern white glass house with flat roof in a foggy forested area surrounded by autumn trees and a well-kept lawn.
Modern house with large glass windows and open floor plan, situated on a hill overlooking a city at dusk.
Modern living room with large glass windows overlooking green trees, featuring a white couch, colorful wall art, and minimalist chairs.
A black silhouette of a wine glass with a decorative filled element on a black background.

Arquitectura Viva N.116 - Ladrillo Visto

By Luis Fernández Galiano

Oct. 31, 2007

En un frondoso paisaje a orillas del río Hudson en el estado de Nueva York se encuentra la primera obra construida por Alberto Campo Baeza en Estados Unidos (abajo), una residencia para la pareja de coleccionistas de piezas de arte contemporáneo italiano Nancy Olnick y Giorgio Spanu. Con el objeto de subrayar la belleza del lugar sin invadirlo, la construcción se compone de dos prismas superpuestos. El inferior - cerrado, estereotómico, de hormigón— alberga los dormitorios de invitados y las áreas de servicio; su

"tapa' es una plataforma de piedra sobre la que se posa un pabellón

-abierto, tectónico, de vidrio— soportado por pilares metálicos cilíndricos siguiendo una trama de seis por seis metros, rematado por una cubierta plana con voladizos de tres metros.

Photo credits: Miguel Quismondo

https://arquitecturaviva.com/publicaciones/av/ladrillo-visto

Magazine cover of 'Arquitectura Viva' featuring a modern architectural interior with perforated concrete walls allowing light to pass through, and a single supporting column.
Modern white building with large glass windows in a park-like setting, surrounded by trees with autumn foliage, green grass, and a stone border.
